- Place of Origin: China
- Brand Name: wooocu
- Model Number: atv
1, Strong structure:The frame structure is reasonable and high strength , through a large number of 3 d simulation analysis and field test ( professional riders high strength test );And We designed and made the frame and linkage all by ourselves in own special workshop, to ensure the real high quality and best performance;
2, Riding comfort: We designed the seat by ourselves and choose the car supplier to make, we choosed the Honda shock supplier for our ATV models except Space1 KD70;
3, Steering performance: When in low speed ,it is light and flexible, easy to operate; When in high speed , the steering is very solid and steady;
4, Small shaking: By matching engine and vehicle, the vehicle vibration is better than the domestic same level models;
5, Warranty: We give 1 year warranty for our ATV models‘ main parts (engine, braking systems, linkages ,frame and suspension).
- Place of Origin: China
- Brand Name: wooocu
- Model Number: atv
1) Engine type: Single Cylinder, 4-stroke, water-cooled, 4-valve
2) Displacement(ml): 594
3) Max Power(kw/r/min): 28/6500
4) Max Torque(N.m/r/min): 46/5500
5) Ignition system: ECU
6) Gear : CVT（L H N R）
7) Fuel tank capacity(L): 10
8）Economical oil exhaust(L/100km): 6.0
9）Max speed(km/h): 80
10）Transmission: Shaft Drive 4*4
11）Brake Type(front / rear): Disc / Disc Brake
12）Wheelbase(mm): 1300
13）Ground clearance(mm): 285
14）Tires (front / rear): 25*8-12 / 25*10-12
15) N. W.(kg): 389 G. W.(kg): 454
16） Product dimension(mm): 2200*1150*1220
17）Carton dimension(mm): 2250*940*1180
18）Qty/40HQ: 18PCS
